ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER

Send Inquiry

Request To Call Back

ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER

Name: ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER
Brand: AMRUTHA TECHNOLOGIES
Price: 8000.0 INR
Availability: InStock

Price 8000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER Specification

Operating Voltage
3V (2 x AAA batteries)

Measuring Range
0.000%-0.199% BAC

Accuracy
0.01% BAC

Display Type
Digital LCD with backlight

Response Time
<5 seconds

Temperature
0C to 50C operating

Features
Portable, lightweight, memory function, auto power-off, easy-to-read display

Automation Grade
Semi-automatic (manual activation)

Mounting Type
Handheld

Power Supply
2 x AAA 1.5V batteries

Port Size
Standard mouthpiece

Specimen Size
Full exhaled breath

Equipment Type
Alcohol Breath Analyser

Test Range
0.000%-0.199% BAC

Resolution
0.001% BAC

Interface Type
Manual buttons (Test/Memory)

Number of Specimens
Single (per breath)

Humidity
Up to 95% RH, non-condensing

Application
Alcohol detection for drivers, industry, workplace safety, personal use

Usage
Personal and professional alcohol level screening

Capacity
Multiple tests per battery set

Machine Weight
Approx. 110g (including batteries)

Test Speed
Within seconds

Test Width
Not Applicable (handheld unit)

Control Mode
Push Button

Working Life of Sensor
>800 tests

Mouthpiece Type
Detachable

Dimension
Approx. 105mm x 62mm x 23mm

Warm-up Time
<10 seconds

Buzzer Alert
Yes

Color
Black

Auto Power Off
Yes

Memory Function
Stores last test result

Battery Low Indication
Yes

Casing Material
ABS Plastic

Model Number
AT560

Sensor Type
Semiconductor alcohol sensor

About ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER

The Alcohol Breath Tester is commonly used at home, bar, laboratory, Police,
Military, and Airport or while you are on the road Device provided with extra
mouthpieces for convenience. Units activated through a micro switch, after a
brief internal self test; the test subject blows through the sensor and result are
converted and read within few seconds.

Fast and Reliable Alcohol Detection

With its advanced semiconductor sensor, the AT-560 delivers accurate alcohol breath analysis in less than five seconds. Designed for efficiency, this handheld analyzer is perfect for quick screenings whether at home, in the workplace, or on the road.

Convenient Features for Everyday Use

The AT-560 includes a detachable mouthpiece, digital LCD with backlight for easy reading, and user-friendly push-button operation. Its auto power-off and battery low alerts ensure extended use, while the memory function stores the previous result for reliable record-keeping.

Durable and Portable Design

Encased in sturdy ABS plastic, the AT-560 weighs approximately 110g with batteries, making it light and robust for repeated use. Its compact size fits comfortably in your hand or pocket, and is suitable for rigorous environments up to 95% humidity and 0C to 50C temperatures.

FAQ's of ALCO TEST. AT-560 ALCOHOL BREATH ANALYSER:

Q: How do I use the ALCO TEST AT-560 Alcohol Breath Analyzer?

A: To use the AT-560, attach a clean, detachable mouthpiece, turn on the device, and wait for the warm-up (less than 10 seconds). Exhale fully into the mouthpiece when prompted, and within a few seconds, the digital display will show your BAC result.

Q: What benefits does the memory function provide?

A: The memory function allows you to easily recall the previous test result, enabling better monitoring of alcohol levels over time and supporting record-keeping for personal or workplace safety requirements.

Q: Where can the AT-560 breath analyzer be used?

A: This breath analyzer is suitable for drivers, workplace safety screening, industrial compliance checks, and personal monitoring, thanks to its portable, handheld design and robust build.

Q: When should I replace the mouthpiece on the AT-560?

A: The detachable mouthpiece should be cleaned or replaced after each use for hygiene reasons, especially when the device is shared among multiple users.

Q: What is the recommended process for maintaining the device for best performance?

A: Regularly clean the mouthpiece, store the device in a dry place, replace AAA batteries when the low battery indicator lights up, and avoid exposing it to extreme temperatures or moisture.

Q: How accurate is this breath analyzer, and what is its measuring range?

A: The AT-560 provides highly accurate readings with a margin of error of 0.01% BAC and a fine resolution of 0.001% BAC, measuring alcohol levels within a 0.000%-0.199% BAC range.
