AMRUTHA NONCONTACT WALLMOUNT

Name: AMRUTHA NONCONTACT WALLMOUNT
Brand: AMRUTHA TECHNOLOGIES
Price: 38000.0 INR
Availability: InStock

Price 38000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

AMRUTHA NONCONTACT WALLMOUNT Specification

Humidity
Up to 95% RH (Non-condensing)

Specimen Size
Direct exhalation

Gas Pressure
Atmospheric

Accuracy
0.01% BAC

Automation Grade
Fully Automatic

Display Type
Digital LCD

Features
Non-contact, Wall-mounted, Touch-free operation, Alert Indicator

Operating Voltage
230V AC

Max Height
Approx. 28 cm

Mounting Type
Wall Mounted

Test Range
0.00% - 0.40% BAC

Equipment Type
Non-Contact Wall-Mount Breath Alcohol Analyzer

Resolution
0.01% BAC

Frequency
50 Hz

Port Size
Standard blow port

Number of Specimens
One per operation

Interface Type
External relay output, optional USB

Temperature
0C to 50C

Measuring Range
0.00% - 0.40% BAC

Power Supply
230V AC, 50Hz

Application
Industrial, Corporate, Security Points

Response Time
< 10 seconds

Usage
Mouthpiece-free breath alcohol screening

Capacity
Continuous use

Machine Weight
Approx. 1.5 kg

Test Speed
Instant result

Test Width
Single user

Control Mode
Automatic, touch-free

Enclosure Material
Industrial Grade ABS/Metal

Alarm Type
Visual & Audible Alarm

Start Mode
Push button or automatic sensing

Data Storage
10000 test results (optional)

Indicator
Multi-color LED Signal Tower (Red, Yellow, Green)

Sensor Type
Advanced Electrochemical (Fuel Cell)

Operation Mode
Ready 24x7 with automatic sleep mode

Calibration
Recommended every 6 months

Protection Class
IP 54

Compliance
CE Marked, ROHS Compliant

Installation Location
Indoor/covered outdoor areas

AMRUTHA NONCONTACT WALLMOUNT Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
7 Days

About AMRUTHA NONCONTACT WALLMOUNT

2. Sensor: Electrochemical Fuel Cell sensor (13x13mm big sensor)
Pressure sensor for flow auto detect
3. BT printing: Option (not included)
4. RTC: Perpetual calendar
5. Memories 65000 Records with time stamp
6. Measurement Accuracy: 0.04 mg/L (0.06BAC) at alert point for screening test
0.025 mg/L (0.05BAC) at alert point for formal test
7. Active/Passive test/ Screening test: Auto detect or passive forced test
8. Power Supply DC 12V
9. Auto flow monitoring. Flow detects automatically
10. Response time About 1 second for screening test and 5 sec. for formal
test
11. Alert indicator: Go no go bi-color alert lamp

Advanced Non-Contact Testing

Equipped with a superior electrochemical (fuel cell) sensor, the AMRUTHA NONCONTACT WALLMOUNT ensures highly accurate, mouthpiece-free alcohol breath screening. Its touch-free design maintains hygiene and eliminates cross-contamination, making it ideal for high-throughput areas such as factories, offices, and security checkpoints.

Reliable Performance and Easy Operation

Operating 24x7, this analyzer initiates tests either automatically or by push button, ensuring readiness at all times. Results appear instantly, complemented by a clear multi-color LED signal system and digital LCD, facilitating quick decision-making and safe workplace management.

Durable and Compliant Design

Constructed with industrial-grade ABS/metal and rated IP54, the device withstands demanding indoor or covered outdoor conditions. Its CE Mark and ROHS compliance guarantee quality and environmental responsibility, making it a trusted choice for safety-critical applications.

FAQ's of AMRUTHA NONCONTACT WALLMOUNT:

Q: How does the AMRUTHA NONCONTACT WALLMOUNT breath analyzer operate?

A: The analyzer uses advanced electrochemical (fuel cell) sensor technology to measure breath alcohol content quickly and accurately. The user exhales toward the sensor in a touch-free manner, and the device automatically provides results on a digital LCD display along with a multi-color LED signal.

Q: What are the installation requirements for this device?

A: The AMRUTHA NONCONTACT WALLMOUNT is designed for wall mounting in indoor or covered outdoor areas. It requires a standard 230V AC, 50Hz power supply and is constructed to withstand dusty or humid environments (up to 95% RH, non-condensing) due to its IP54-rated enclosure.

Q: When should the analyzer be calibrated?

A: Calibration is recommended every 6 months to ensure measurement accuracy and reliable performance, especially in environments with frequent use.

Q: Where can this breath alcohol analyzer be used effectively?

A: The device is suitable for use in industrial plants, corporate offices, security points, and any location requiring fast, hygienic, and reliable alcohol screening of personnel.

Q: What is the process for testing and retrieving results?

A: Testing is fully automatic or can be initiated by push button. The user simply exhales directly toward the blow port; results display instantly (within 10 seconds) on the LCD and are visually indicated by the LED tower. Optional data storage allows up to 10,000 results to be recorded for later retrieval.

Q: What are the usage benefits of the non-contact, wall-mount design?

A: This equipment eliminates the need for disposable mouthpieces, reducing operating costs and the risk of cross-contamination. Its wall-mount design saves space and enables continuous, efficient operation in high-traffic locations.

Q: How accurate and reliable are the test results?

A: The analyzer offers a high accuracy of 0.01% BAC with instant response and a measuring range of 0.00%-0.40% BAC, making it suitable for compliance and safety-critical screening in professional environments.
